18 Technical data industrial router mbNET.mini MDH 860 – MDH 867
(Type: MDH 860, MDH 862 AT&T, MDH 862 EU, MDH 863, MDH 866 AT&T, MDH 866 EU, MDH 867).
From hardware version HW02, HW03* and firmware version from V 2.2.0
* You will find the hardware version on the device
nameplate.
General data
Voltage V (DC) 10 - 30 V DC (SELV and Limited Energy circuit)
Power consumption (Normal
mode)
250 mA @ 24 V - without additional consumers
Power consumption under full load max. 1.8 A @ 24 V - (including 2 digital outputs + USB port)
Random Access Memory 128 MB
Processor speed 454 MHz
IP protection class IP 30**
** at full occupancy of all connections and interfaces. Alternatively, unused inter-
faces can be covered with dust protection plugs.
Area of application Dry environments
Operating temperature -40 – +75 °C (Type: MDH 860, MDH 862, MDH 866)
-40 – +75 °C (Type: MDH 863, MDH 867 - HW 03)
Operating temperature 0 – +60 °C (Type: MDH 863, MDH 867 - HW 02)
Storage temperature -40 – +85 °C
Humidity 0 – 95% (non condensing)
Weight (max.) 240 g
Dimensions (max.) 69 mm x 38.5 mm x 92.5 mm (W x D x H)
Housing (material) metal
Mounting DIN rail mounting (based on DIN EN 50022)
Technical data industrial router mbNET.mini MDH 860 – MDH 867 | Page 127 of 131
