13.3.2.3 Firewall Settings - Create new Forwarding
Navigation: Administration > Projects > ProjektAlpha (selected project) > RouterAlpha (selected device) >
Services > Firewall
This setting is forwarding requests from specific IP addresses and ports to defined IP addresses and ports.
Image 8: Depending on the device and type, individual display / selection fields may vary.
Forwarding
Active Checkbox for activating / deactivating this rule.
Source IP You can enter the IP addresses from which data packets are received here.
If an entry is made here, only packets from these addresses are forwarded.
Source Port You can specify the ports via which the data packets arrive here.
If an entry is made here, only packets specifically sent via this port are forwarded.
Protocol The following options are available for selection:
•
All - the set rule applies to all protocols.
•
TCP - the set rule only applies to the TCP protocol.
•
UDP - the set rule only applies to the UDP protocol.
•
ICMP - the set rule only applies to the ICMP protocol.
Destination IP Enter the IP addresses to which the data packets were originally to be sent here.
Destination Port Specify the ports via which the data packets are sent to the destination IP here.
Page 94 von 131 | Version: 2.2.1 - EN | Mar 28
th
, 2022 |
