WAN > LAN
LAN interface Use this selection field to specify the LAN interface to which the rule is to be applied. You
can choose from:
•
local Services
•
LAN ethernet
•
All
Source IP Here, enter the IP addresses for whose incoming data packets one of the set actions is
to be executed.
If you leave the field blank, the set action applies to all IP addresses (only on the select-
ed interface).
Source Port Enter the ports via which the data packets arrive here.
Protocol The following options are available for selection:
•
All - the set rule applies to all protocols.
•
TCP - the set rule only applies to the TCP protocol.
•
UDP - the set rule only applies to the UDP protocol.
•
ICMP - the set rule only applies to the ICMP protocol.
WAN interface This setting defines the WAN interface to which the rule is to be applied.
•
Internet
•
WAN Ethernet
•
OpenVPN
•
All
Destination IP Enter the IP addresses to which the data packets are to be forwarded here.
Destination Port Enter the ports via which the data packets are forwarded here.
NOTICE
You can enter address ranges in the input fields for the IP address.
Example of address ranges: 192.168.0.100-192.168.0.110 or 192.168.0.20/30
Address listings are not possible!
In the input fields for the ports, you can enter ranges or enumerations.
Example of a port range: 502-504
Example of port enumeration: 502,677,555
Both, range and enumeration can not be used simultaneously in the same field.
NOTICE
Ranges must be separated by a hyphen (-) and enumerated by comma (,).
No spaces between the elements to be separated!
NOTICE
The input of IP and port is not mandatory. If neither an IP nor a port is specified, a rule applies only to
the selected interfaces.
Configuring your Router in the Remote Service Portal (V 2.x) | Page 93 of 131
