WAN > LAN
Active Checkbox for activating / deactivating this rule.
Action The following options are available for selection:
•
DROP
If this option is selected, it means that no data packets can pass and the packets
are also deleted immediately. The sender is not notified about the whereabouts of
the data packets.
•
REJECT
If this option is selected, the data packets are rejected. The sender is notified that
the data packets have been rejected.
•
ACCEPT
If this option is selected, the data packets can pass.
WAN Interface This setting defines the WAN interface to which the rule is to be applied.
•
Internet
•
WAN Ethernet
•
OpenVPN
•
All
Source IP Here, enter the IP addresses for whose incoming data packets one of the set actions is
to be executed.
If you leave the field blank, the set action applies to all IP addresses (only on the select-
ed interface).
Source Port Enter the ports via which the data packets arrive here.
Protocol The following options are available for selection:
•
All - the set rule applies to all protocols.
•
TCP - the set rule only applies to the TCP protocol.
•
UDP - the set rule only applies to the UDP protocol.
•
ICMP - the set rule only applies to the ICMP protocol.
LAN interface Use this selection field to specify the LAN interface to which the rule is to be applied. You
can choose from:
•
local Services
•
LAN ethernet
•
All
Destination IP Enter the IP addresses to which the data packets are to be forwarded here.
Destination Port Enter the ports via which the data packets are forwarded here.
Page 90 von 131 | Version: 2.2.1 - EN | Mar 28
th
, 2022 |
