Installation Specications
Electrical
The MEDIVATORS
®
ADVANTAGE PLUS
®
Automated Endoscope Reprocessor must be connected to a
single electrical outlet capable of supplying 1000 watts at 100-240 volts AC, 50/60 Hz. The outlet must
be properly grounded.
Water
Potable water is the minimum standard. For optimum performance, water must be delivered at a minimum
ow rate of 5 L/min (1.32 gpm) at a dynamic pressure of 30 psi (2 bar) during the basin ll. For optimum
performance water must be delivered at 35ºC by use of a mixing valve (required). The mixing valve
must be purchased separately and installed by the facility. A back siphonage prevention device must be
purchased separately and installed between the water line & the reprocessor to prevent contamination of
the water supply in the event of a sudden drop in water pressure.
Drain
For optimum performance the MEDIVATORS ADVANTAGE PLUS System should be connected to a
vented sanitary drain system capable of draining at a minimum rate of 12 L/min (3.17 gpm).
Room Ventilation
The MEDIVATORS ADVANTAGE PLUS System must be installed in a room with a ventilation system
capable of delivering a minimum of 10 air exchanges per hour.
An optional vapor management system is available for ductless fume removal.
Air
The MEDIVATORS ADVANTAGE PLUS System must be connected to an air supply for proper
operation. The ADVANTAGE PLUS system includes an air compressor that requires a dedicated 120
VAC, 20 Ampere service or 230 VAC, 10 Ampere service. The air compressor delivers proper air ows
and pressure for correct system operation.
If the ADVANTAGE PLUS model purchased did not include the air compressor, the system may utilize
house compressed air (dry, oil free) which must meet these required air pressure specications : 58 to 125
PSI with a minimum ow volume of 1.5 CFM, maximum particle size is 5 microns, maximum dew point
is 7°C (45°F), maximum oil concentration is 5 mg/m
3
.
