Medivators ADVANTAGE PLUS - User, Endoscope, and Physician Registration

145
Figure 5 Export Dialog Window
Bar Codes
The MEDIVATORS
®
ADVANTAGE PLUS
®
Automated Endoscope Reprocessor is supplied with a set of
barcode labels to be used with the endoscopes, operators, physicians and assistants.
The barcode label mounted on the endoscope should be placed on the control head handle on the knob side
so the barcode is visible when endoscope is place in the basin. Before the barcode label is attached to the
endoscope clean the surface of the endoscope with alcohol and dry.
The barcode label for the operator can be placed on the operator’s ID badge or on the barcode scanner
shelf mounted on the right side of the MEDIVATORS ADVANTAGE PLUS system.
The supplied set is numbered 100 to 199 and includes 2 barcode labels per number. Duplicate barcode
labels can be ordered with part number 67199-157. A barcode label set number 200-299 can be ordered
with part number 67199-158.
Endoscope Registration
Categorizing Endoscopes
WARNING Incorrectly categorizing an endoscope may result in incomplete disinfection. If you
have questions about an endoscope, contact the endoscope manufacturer or technical service
for advice.
