Water Filter Replacement
WARNING: Only replace one water lter at a time. When replacing the water lter, make sure that
the lter being removed is the same as the lter replacing it.
The water ltration system removes particulates and biological contaminants as small as 0.1 micron from
the supply water. During the water line disinfection procedure, the entire water ltration system and the
incoming water line for the MEDIVATORS
®
ADVANTAGE PLUS
®
Automated Endoscope Reprocessor
is disinfected.
Note: A water line and water ltration disinfection process must be performed whenever a water lter is
replaced. Refer to Chapter 2 Waterline and Water Filter Disinfection.
Figure 4 Water Filtration System
1. Water inlet (1/2” NPT) 7. 1 micron lter 12. Bleed valve
2. Inlet pressure gauge 8. 0.4 micron lter 13. Bleed valve outlet
3. 1 micron lter outlet pressure gauge 9. Disinfectant inlet 14. 0.1 micron lter
4. 0.4 micron lter outlet pressure gauge 10. Water lter feed line
5. 0.1 micron lter inlet pressure gauge 11. Communication cable connector
6. Water outlet
