55
Table 1 Acceptable Pressure Ranges
Pressure Control Acceptable Pressure Range
Main Air Pressure 42 – 45 psi (2.8–3.0 bar)
Leak Test Air Pressure 3.6 – 3.75 psi (0.24–0.25 bar)
Channel Connectivity 25.5 – 30 psi (1.7 – 2.0 bar)
If the pressure control readings do not fall within the acceptable ranges, contact technical service. Do
not attempt to adjust the settings yourself as damage may occur to the MEDIVATORS
®
ADVANTAGE
PLUS
®
Automated Endoscope Reprocessor.
O-Rings
Check the connection manifolds to verify that all the O-rings are present and undamaged. The manifolds
are located in each basin and are the studs onto which the connector block slides down and seals.
Figure 2 Connection Manifold
Drain Filters
Replace the lters in the rinse basin if they are excessively soiled (See Appendix B for replacement
part numbers).
