Megmeet M5-N Series User Manual

Chapter 8 Drive Parameter Object
116
Parameter
No.
Sub-index
Name
Setting range
Minimum
unit
Default value
Effective
time
Property
initialization
changing status
1: Clear fault memory
information
2: Restore to
leave-factory value
P02.23
18h
LED display
parameter
selection
0: Switching display
P11.00
1: Switching display
P11.01
2: Switching display
P11.02
3: Switching display
P11.03
4: Switching display
P11.04
5: Switching display
P11.05
......
1
0
Immediate
During
running
P02.24
19h
DI enable terminal
valid type selection
0: Level valid
1: Transition edge
valid
1
1
Immediate
During
running
Index 2003h(P03): Digital input and output terminal parameters
P03.00
01h
DI1 terminal
function selection
0: No function
1: Servo enable
2: External reset
(RESET) input
3: Gain switching
4: Multi-speed DI
switching running
direction
5: Multi-segment
operation reference
switching 1
6: Multi-segment
operation reference
switching 2
7: Multi-segment
1
1
Immediate
At stop
P03.01
02h
DI2 terminal
function selection
1
2
Immediate
At stop
P03.02
03h
DI3 terminal
function selection
1
3
Immediate
At stop
P03.03
04h
DI4 terminal
function selection
1
35
Immediate
At stop
P03.04
05h
DI5 terminal
function selection
1
36
Immediate
At stop
P03.05
06h
Reserved
1
0
Immediate
At stop
P03.06
07h
Reserved
1
0
Immediate
At stop
P03.07
08h
Reserved
1
0
Immediate
At stop
P03.08
09h
Reserved
1
0
Immediate
At stop
