Megmeet M5-N Series User Manual

Chapter 2 Servo System Specifications
17
Torque control
Performance
Torque control
accuracy
±1%
Frequency
characteristics
3kHz
Control input
Zero speed clamp, torque command symbol input, etc.
Control output
Speed arrival etc.
Speed limit function
The speed limit value can be set according to the parameters
2.2 Servo motor standard specifications
2.2.1 Servo motor basic specifications
Table 2-3 General basic specifications of servo motors
Servo motor basic index items
Protection degree
IP65
Ambient temperature
0℃~+40℃
Ambient humidity
Relative humidity <90% (no frost condition)
Installation method
Flange mounted
Insulation resistance
50MΩ (500V)
Insulation voltage
1500V (220V motor)
1800V (380V motor)
Insulation class
F
2.2.2 Servo motor rated specifications
Table 2-4 Servo motor standard specifications
Motor model
Rated
voltage
(V)
Rated
power
(kW)
Rated
speed
(RPM)
Maximum
speed
(RPM)
Rated
torque
(N.m)
Peak
torque
(N.m)
Rated
current
(A)
Peak
current
(A)
Rotor inertia
(10
-4
kg.m
2
)
SPM-SC*0401M**-L
220
0.1
3000
6000
0.32
0.95
0.92
2.85
0.062(0.072)
SPM-SC*0602M**-L
220
0.2
3000
6500
0.64
1.91
1.5
4.66
0.28(0.3)
SPM-SC*0604M**-L
220
0.4
3000
5000
1.27
3.81
2.1
6.5
0.56(0.58)
SPM-SC*0807M**-L
220
0.75
3000
5000
2.39
7.17
4.1
13.4
1.5(1.65)
SPM-SC*0810M**-L
220
1
3000
5000
3.19
9.56
5.7
17.7
2(2.15)
Note: Parameters in parenthesis is the parameter of the motor with brake.
