Megmeet M5-N Series User Manual

Chapter 2 Servo System Specifications
15
Chapter 2 Servo System Specifications
2.1 Servo drive standard specifications
2.1.1 Servo drive electrical specifications
Table 2-1 Drive list and electrical specifications
Voltage level
220V
Model
M5-NS1R6A
M5-NS2R8A
M5-NS5R5A
M5-NS7R6A
Power level
200W
400W
750W
1kW
Outline
SIZE A
SIZE B
Phase
Single phase
Single/three phase
Rated input
current (A)
2.3
4
7.6/3.7
9.6/5.1
Rated output
current (A)
1.6
2.8
5.5
7.6
Maximum output
current (A)
5.8
9.3
16.9
20
Main circuit power
supply
200~240V, -10%~+10%, 50/60HZ
Braking resistor
No built-in
braking resistor
Built-in
braking resistor
2.1.2 Servo drive basic specifications
Table 2-2 Servo drive basic specifications
Basic specifications
Basic
specifications
Control mode
IGBT, PWM control, sine wave current drive mode
Encoder
Rotating
motor
Absolute encoder
Control IO
DI
Different
functions
configured
according
to parameters
5 general inputs, optocoupler isolation, NPN and PNP inputs can be
selected
Input voltage range 20~30V, input impedance 3.9K
DO
Different
functions
configured
according
to parameters
3 general outputs, optocoupler isolation, NPN and PNP output can be
selected
Maximum operating voltage 30V, maximum current 100mA
