Chapter 3 Installation Description
Chapter 3 Installation Description
3.1 Servo drive installation
3.1.1 Installation site
Installed in a cabinet free from direct sunlight or water droplets and rain
Avoid installing in dusty, metal powder, high temperature or humid places
It is strictly forbidden to install in places with corrosive or flammable and explosive gases
No vibration place
3.1.2 Installation environment requirements
Table 3-1 M5-N servo drive installation environment requirements
Install it vertically on a solid base indoors, with at least 5cm of space for
inlet and outlet, and at least 2cm of space for left and right sides of the
case. The cooling medium is air.
0 ~+45℃, the air temperature change is less than 0.5℃/min;
Derating can be used above 45℃, and keep good ventilation, the maximum
temperature is 55℃ (can run at 25% normal load)
Relative humidity <90% (no condensation)
No condensation, icing, rain, snow, hail, etc., the solar radiation is lower
than 700W/m
2,
and the air pressure is 70~106kPa.
Salt spray and
corrosive gas
content
Dust and solid
particle content
Used at the place lower than 1000m (derated at the place above 1000m,
derated 6% for every increase of 1000m)
3.1.3 Servo drive installation precautions
Installed in an indoor, well-ventilated place, generally installed in a cabinet, and installed vertically, and securely
fixed on the mounting surface through the two fixing holes of the drive.
When SIZEA and SIZEB are installed in compact sizes, consider the installation error. The spacing between them
must be at least 2mm. In this case, the actual load ratio needs to be derated. (SIZEA:Actual load ratio ≤70%.
