Megmeet M5-N Series User Manual

Chapter 8 Drive Parameter Object
120
Parameter
No.
Sub-index
Name
Setting range
Minimum
unit
Default value
Effective
time
Property
17: Electrical homing
completed
18: Brake output
(brake output signal)
19: Torque arrival
signal
20: FWD/REV
indication terminal
21: Reserved
22: Positioning
position arrival 1
23: Positioning
position arrival 2
24: Positioning
position arrival 3
25: Positioning
position arrival 4
26: Positioning
position arrival 5
27: Interrupt
positioning completed
P03.21
16h
Reserved
P03.22
17h
Reserved
P03.23
18h
Output terminal
enabled status
setting
Binary setting
0: Enabled upon
connection
1: Enabled upon
disconnection
Unit place of LED:
BIT0~BIT3:
DO1~DO4
1
00
Immediate
During
running
Index 2005h(P05): Position control parameters
P05.00
01h
Position reference
mode
0: Pulse reference
1: Single point
position reference
2: Multi-segment
position reference
1
0
Immediate
At stop
