Megmeet M5-N Series User Manual

Chapter 8 Drive Parameter Object
119
Parameter
No.
Sub-index
Name
Setting range
Minimum
unit
Default value
Effective
time
Property
Tens place of LED:
BIT0: DI5
P03.14
0Fh
Virtual input
terminal setting
Binary setting:
0: Disabled
1: Enabled
Unit place of LED:
BIT0~BIT3: DI1~DI4
Tens place of LED:
BIT0: DI5
1
000
Immediate
During
running
P03.15
10h
DO1 function
selection
0: Servo drive ready
(RDY)
1: Servo drive
running signal (RUN)
2: The speed is
consistent
3: Speed arrival
signal
4: Zero speed
operation
5: Drive fault
6: Drive alarm
7: Host device switch
signal
8: Torque limit
9: Speed limit
10: Zero servo
completed
11: Positioning
completed
12: Positioning close
to
13: Position tolerance
alarm
14: Homing
15: Homing
completed
16: Electrical homing
1
0
Immediate
At stop
P03.16
11h
DO2 function
selection
1
5
Immediate
At stop
P03.17
12h
DO3 function
selection
1
18
Immediate
At stop
P03.18
13h
Reserved
1
0
Immediate
At stop
P03.19
14h
Reserved
1
0
Immediate
At stop
P03.20
15h
Reserved
1
0
Immediate
At stop
