Megmeet M5-N Series - Index 200 Bh(P11): Display Parameters

Chapter 8 Drive Parameter Object
143
Parameter
No.
Sub-index
Name
Setting range
Minimum
unit
Default value
Effective
time
Property
P10.53
36h
Q-axis current
feedback value at
the first fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.54
37h
Speed at the first
fault
-6000.0~6000.0rpm
0.1rpm
0.0
_
At
display
P10.55
38h
Encoder position
feedback at the
first fault
(PUU unit)
-2147483648~21474
83647
1
0
_
At
display
P10.56
39h
DI status at the
first fault
Unit place of LED:
BIT0~BIT3: DI1~DI4
Tens place of LED:
BIT0: DI5
1
0
_
At
display
P10.57
3Ah
DO status at the
first fault
Unit place of LED:
BIT0~BIT2:
DO1~DO3
1
0
_
At
display
P10.58
3Bh
Drive status at the
first fault
0~FFFFH
(the same as P11.11)
1
0
_
At
display
P10.59
3Ch
Temperature at the
first fault
-40.0℃~200.0℃
0.1℃
0.0
_
At
display
Index 200Bh(P11): Display parameters
P11.00
01h
Speed command
-6000.0~6000.0rpm
0.1rpm
_
At
display
P11.01
02h
Actual motor
speed
-6000.0~6000.0rpm
0.1rpm
_
At
display
P11.02
03h
Output voltage
0~480V
1V
_
At
display
P11.03
04h
Output current
0.0~4Ie A
0.1A
_
At
display
P11.04
05h
Q-axis current
-400.0~+400.0%Ie
0.1%
_
At
display
P11.05
06h
D-axis current
-100.0~+100.0%Ie
0.1%
_
At
display
P11.06
07h
Output torque
-300.0~+300.0%
0.1%
_
At
display
