Chapter 8 Drive Parameter Object
142
Parameter
No.
Sub-index
Name
Setting range
Minimum
unit
Default value
Effective
time
Property
the second fault
P10.40
29h
Q-axis current
feedback value at
the second fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.41
2Ah
Speed at the
second fault
-6000.0~6000.0rpm
0.1rpm
0.0
_
At
display
P10.42
2Bh
Encoder position
feedback at the
second fault
(PUU unit)
-2147483648~21474
83647
1
0
_
At
display
P10.43
2Ch
DI status at the
second fault
Unit place of LED:
BIT0~BIT3: DI1~DI4
Tens place of LED:
BIT0: DI5
1
0
_
At
display
P10.44
2Dh
DO status at the
second fault
Unit place of LED:
BIT0~BIT2:
DO1~DO3
1
0
_
At
display
P10.45
2Eh
Drive status at the
second fault
0~FFFFH
(the same as P11.11)
1
0
_
At
display
P10.46
2Fh
Temperature at the
second fault
-40.0℃~200.0℃
0.1℃
0.0
_
At
display
P10.47
30h
The bus voltage at
the first fault
0~999V
1V
0
_
At
display
P10.48
31h
V-phase current at
the first fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.49
32h
W-phase current at
the first fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.50
33h
D-axis current
reference value at
the first fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.51
34h
Q-axis current
reference value at
the first fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.52
35h
D-axis current
feedback value at
the first fault
0.0~999.9A
0.1A
0.0
_
At
display
