Chapter 8 Drive Parameter Object
141
Parameter
No.
Sub-index
Name
Setting range
Minimum
unit
Default value
Effective
time
Property
feedback value at
the last fault
display
P10.27
1Ch
Q-axis current
feedback value at
the last fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.28
1Dh
Speed at the last
fault
-6000.0~6000.0rpm
0.1rpm
0.0
_
At
display
P10.29
1Eh
Encoder position
feedback at the
last fault
(PUU unit)
-2147483648~21474
83647
1
0
_
At
display
P10.30
1Fh
DI status at the last
fault
Unit place of LED:
BIT0~BIT3: DI1~DI4
Tens place of LED:
BIT0: DI5
1
0
_
At
display
P10.31
20h
DO status at the
last fault
Unit place of LED:
BIT0~BIT2:
DO1~DO3
1
0
_
At
display
P10.32
21h
Drive status at the
last fault
0~FFFFH
(the same as P11.11)
1
0
_
At
display
P10.33
22h
Temperature at the
last fault
-40.0℃~200.0℃
0.1℃
0.0
_
At
display
P10.34
23h
The bus voltage at
the second fault
0~999V
1V
0
_
At
display
P10.35
24h
V-phase current at
the second fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.36
25h
W-phase current at
the second fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.37
26h
D-axis current
reference value at
the second fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.38
27h
Q-axis current
reference value at
the second fault
0.0~999.9A
0.1A
0.0
_
At
display
P10.39
28h
D-axis current
feedback value at
0.0~999.9A
0.1A
0.0
_
At
display
