Megmeet M5-N Series User Manual

Chapter 8 Drive Parameter Object
121
Parameter
No.
Sub-index
Name
Setting range
Minimum
unit
Default value
Effective
time
Property
P05.01
02h
Pulse command
input terminal
selection
0: Low-speed
terminal
1: High-speed
terminal
1
1
Immediate
At stop
P05.02
03h
Pulse command
mode
0: A/B phase pulse
1: PULS+SIGN
2: CW/CCW pulse
1
0
Immediate
At stop
P05.03
04h
Pulse command
logic
0: Positive logic
1: Inverse logic
1
0
Immediate
At stop
P05.04
05h
Reserved
P05.05
06h
Pulses for
one motor
revolution
0~8388608 P/r
1 P/r
8388608
Immediate
At stop
P05.06
07h
Position command
first-order
low-pass filter time
0.0~2000.0ms
0.1ms
0
Immediate
During
running
P05.07
08h
Position command
moving average
filter time
0.0~12.8ms
0.1ms
0
Immediate
During
running
P05.08
09h
Electronic gear
ratio numerator
1~1073741824
1
8388608
Immediate
At stop
P05.09
0Ah
Electronic gear
ratio denominator
1
1~1073741824
1
10000
Immediate
At stop
P05.10
0Bh
Electronic gear
ratio denominator
2
1~1073741824
1
10000
Immediate
At stop
P05.11
0Ch
Electronic gear
ratio denominator
3
1~1073741824
1
10000
Immediate
At stop
P05.12
0Dh
Electronic gear
ratio denominator
4
1~1073741824
1
10000
Immediate
At stop
P05.13
0Eh
Electronic gear
ratio switching
conditions
0: Position command
is 0, switch after 3ms
duration
1
0
Immediate
At stop
