Chapter 1 M5-N Servo System Selection
14
Table 1-5 Cable description
No.
Model
Name
Description
Cable
diameter
(mm
2
)
1
SPL-MZ01-M5-xx-x
Main motor
cable (40 base)
Main motor cable, motor side Amp female connector
0.25
2
SPL-MA04-M5-xx-x
Main motor
cable (60/80
base)
Main motor cable, motor side Amp female connector
0.75
8
SPL-E01-M5-xx-x
Multi-turn
absolute
encoder cable
Drive side 6-pin male connector, motor side 9-pin Amp
female connector (with battery case)
—
9
SPL-E05-M5-xx-x
Single-turn
absolute
encoder cable
Drive side 6-pin male connector, motor side 9-pin Amp
female connector (without battery case)
—
