Megmeet M5-N Series User Manual

Chapter 8 Drive Parameter Object
146
Parameter
No.
Sub-index
Name
Setting range
Minimum
unit
Default value
Effective
time
Property
P11.33
22h
Absolute encoder
rotation data
0~65535r
1r
_
At
display
P11.34
23h
Load moment of
inertia ratio
0.00~120.00
0.01
_
At
display
P11.35
24h
Absolute position
PUU value
Machine current
absolute position
(command unit)
= mechanical
absolute position /
mechanical gear ratio
-2147483648~21474
83647
Comman
d unit
_
At
display
P11.36
25h
Mechanical
absolute position
(lower 32 bits)
In absolute position
linear mode or
absolute position
rotary mode, the load
position is converted
to the position of the
motor side (encoder
unit)
Mechanical absolute
position = encoder
absolute position -
origin offset
Encoder
unit
_
At
display
P11.37
26h
Mechanical
absolute position
(upper 32 bits)
Encoder
unit
_
At
display
P11.38
27h
Absolute encoder
absolute position
(lower 32 bits)
The absolute position
of the absolute
encoder feedback.
Encoder unit
Encoder
unit
_
At
display
P11.39
28h
Absolute encoder
absolute position
(upper 32 bits)
Encoder
unit
_
At
display
P11.40
29h
Rotating load
single-turn position
(lower 32 bits)
In the absolute
position rotation
mode, the position
within one revolution
of the rotating load is
converted to the
motor position of the
motor side.
Encoder
unit
_
At
display
P11.41
2Ah
Rotating load
single-turn position
(upper 32 bits)
Encoder
unit
_
At
display
