Megmeet M5-N Series User Manual

Chapter 9 Troubleshooting
159
Fault code
Fault type
Fault cause
Confirming method
Solutions
The communication cable
is wired incorrectly or
unreliably connected,
disconnected, etc.
Check whether the
communication cable is
correct and reliable.
Reconnect the communication
cable, or replace the communication
cable.
Improper setting of fault
parameters.
Check whether the
P15.02 setting is too
short.
Set P15.02 correctly.
The host device does not
work.
Confirm the host system
signal
Check whether the host device is
working.
Er.016
Current detection
circuit abnormal
The wirings or the plug-in
units of the control board
loosens.
Check whether the
control board cables and
plug-in units are loose
Check them and rewiring
The AI analog input
voltage is too high.
Check whether the AI
analog voltage input is
above 12V
Adjust AI analog input.
Er.018
Poor auto-tuning
The parameters of the
motor are incorrect.
Confirm the motor
nameplate parameters
Re-enter the correct motor
parameters.
When reverse running is
prohibited, reverse
rotating auto-tuning is
performed.
Confirm whether it is set
to prohibit reverse
function.
Cancel the reverse running
prohibition
Motor wiring is wrong.
Check motor wiring.
Confirm that the UVW power cable
is connected properly and the
phase sequence is correct.
Er.019
Encoder fault
Encoder type error
Check encoder type
Enter the correct encoder
parameters.
Encoder disconnection
Check encoder cable
Replace encoder cable.
Er.020
Undervoltage
during main
circuit operation
Grid voltage drop
Measure whether the grid
voltage is abnormal
Improve the power grid.
The load is too large or
the motor does not match
the drive
Confirm the load
matching conditions
Select the appropriate drive and
motor.
Er.022
The control mode
parameter setting
is incorrect
Parameter identification
is performed in non-VC
control mode.
Confirm the setting of the
control mode in the
parameter.
Confirm the control mode
parameters.
