MAINTENANCE SERVICE MANUAL NUMBER 22
Page 1B-26 90-860074--1 FEBRUARY 2002
REMOVAL
NOTICE
Refer to Precautions BEFORE proceeding.
NOTE: Place a suitable container under fuel filter to catch contaminated fuel and/or water
1. Twist locking ring by hand. Remove water separating fuel filter and sealing ring from
mounting bracket. Do NOT use a filter wrench.
70161
75579
a
b
a-Locking Ring
b-Filter Element
IMPORTANT: Element cannot be cleaned and reused. It must be replaced.
2. Remove the drain cap and O-ring from bottom of the existing filter. Note position of
O-ring seal.
3. Inspect and replace damaged components.
To Next Page
