EDI DIAGNOSIS
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 5E-19
Connector Chart (continued)
Wire Color
Diagnostic
Trouble
ECM Pin Circuit Designation
Wire Color
Abbreviation
Codes
DTC(s)
ScanTool
44 Unused - -
45 Battery Feed RED P1600
46 Battery Minus BLK P1600
47 Unused - -
48 Unused - -
49 Fuel Quantity Actuator GRN/WHT P1220
50 Glow Plug Relay (control side) BLU/BLK P1635
51 Solenoid Valve for Timing BLU P1630
52 Fuel Quantity Sensor (Measure Coil) BLU/YEL P1225
53 Electric Shut Off Device YEL P1660
54 Unused - -
55
a. Throttle Position Sensor Ground
b. MAP / IAT Sensor Ground
a. BLU/WHT
b. BLU/WHT
a. P1515
b. P1110
56 Unused - -
57 TP Sensor - 5 Volt PNK/YEL P1515
58 Unused - -
59 Unused - -
60 Unused - -
61 K-Line GRN/RED
62 Unused - -
63 Fuel Temperature Sender BLU/RED P0180
64 Air Intake temperature Sensor Signal GRN/BLK P1110
65 Low Idle Position Switch BRN/RED P1515
66 Unused - -
67 Unused - -
68 Battery Feed RED P1600
