3.10.1.3 Resetting the Measured Data Output Function
BCD or analog output of measurands is terminated for the duration of the hold
time if one of the following conditions is met:
●
The measured data output is reset either via a setting parameter or via an
appropriately configured binary signal input.
●
There is a general reset.
●
LED indicators reset
S8Z52H6A
MEASO:
Output reset
[ 037 117 ]
MEASO:
Reset meas.val.outp.
304 601
0
0: don't execute
1: execute
MEASO:
Reset output USER
[ 037 116 ]
1
MAIN:
Reset indicat. USER
[ 021 010 ]
1: execute
MAIN:
General reset USER
[ 003 002 ]
1: execute
MEASO:
Reset output EXT
[ 036 087 ]
1
Fig. 3-33: Resetting the measured data output function.
3.10.1.4 Scaling
Scaling is used to map the physical measuring range to the P631 inherent setting
range.
Scaling of analog output is also suited for directional-signed output of some fault
measurands, in particular fault location in percent.
P631
3 Operation
3-48 P631/EN M/R-11-C // P631-310-650
