Micom P631 - Control and Testing

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LOGIC: Output 31
042 092
0: No
[spacer]
LOGIC: Output 31 (t)
042 093
0: No
[spacer]
LOGIC: Output 32
042 094
0: No
[spacer]
LOGIC: Output 32 (t)
042 095
0: No
Parameter Address
Default Min Max Unit Logic Diagram
Programmable Logic
LOG_2: Enabled
011 138
0: No Fig. 3-142, (p. 3-175)
[spacer]
LOG_2: Output 1
052 032
0: No Fig. 3-142, (p. 3-175)
[spacer]
LOG_2: Output 1 (t)
052 033
0: No Fig. 3-142, (p. 3-175)
[spacer]
LOG_2: Output 2
052 034
0: No
[spacer]
LOG_2: Output 2 (t)
052 035
0: No
[spacer]
LOG_2: Output 3
052 036
0: No
[spacer]
LOG_2: Output 3 (t)
052 037
0: No
[spacer]
LOG_2: Output 4
052 038
0: No
[spacer]
LOG_2: Output 4 (t)
052 039
0: No
8.1.2 Control and Testing
Parameter Address
Default Min Max Unit Logic Diagram
Local control panel
LOC: Param. change enabl.
003 010
0: No
[spacer]
Setting the enable for changing values from the local control panel.
P631
8 Information and Control Functions
8-82 P631/EN M/R-11-C // P631-310-650
