227.9
253.6
177.5
101.6
6.4
224.5
242.6
101.6
186.5
213.4
242.6
260.2
‑X6
Fig. 4-4: Flush-mounted case 40 TE with panel opening, flush-mount method 2 (with angle brackets and frame).
(Dimensions in mm.)
The device has increased mechanical robustness if flush-mount method 2 (with
angle brackets and frame) is used for the flush-mounted case.
4.2.2 Detachable HMI
Fig. 4-5: View of case 40 TE for connection of detachable HMI.
4 Design
P631
P631/EN M/R-11-C // P631-310-650 4-5
