2.2 General Data
2.2.1 General Device Data
Design
●
Surface-mounted case suitable for wall installation, or
●
Flush-mounted case for 19″ cabinets and for control panels.
Installation Position
●
Vertical ± 30°.
Degree of Protection
Per DIN VDE 0470 and EN 60529 or IEC 529.
●
IP 52 for the front panel.
●
Flush-mounted case:
■
IP 50 for the case (excluding the rear connection area)
■
IP 20 for the rear connection area, pin-terminal connection
■
IP 10 for the rear connection area, ring-terminal connection
●
Surface-mounted case:
■
IP 50 for the case
■
IP 50 for the fully enclosed connection area with the supplied rubber
grommets fitted
Weight
●
Approx. 7 kg
Dimensions and Connections
See dimensional drawings (Section 4.2, (p. 4-4)), and the location and
terminal connection diagrams (Section 5.7, (p. 5-18)).
Terminals
PC interface (X6)
●
EIA RS232 (DIN 41652) connector, type D-Sub, 9-pin
Communication interfaces COMM1, COMM2
●
Fiber (X7, X8)
■
F-SMA optical fiber connection per IEC 60874‑2 (for plastic fibers), or
■
optical fiber connection BFOC-ST
®
connector 2.5 per IEC 60874‑10‑1 (for
glass fibers).
(ST
®
is a registered trademark of AT&T Lightguide Cable Connectors.)
●
Wire leads (X9, X10)
■
M2 threaded terminal ends for wire cross-sections up to 1.5 mm² (US:
AWG16).
●
IRIG-B Interface (X11)
■
BNC plug
