3.24.2 Readiness of Thermal Overload Protection
Thermal overload protection will issue the THRM1: Not ready signal if one of
the following conditions applies:
Thermal overload protection is disabled.
Thermal overload protection is blocked because of a fault in the coolant
temperature (ambient) acquisition.
Thermal overload protection is blocked because of an incorrect setting.
The thermal replica is blocked via an appropriately configured binary signal
input.
64Z5190A
THRM1:
Not ready
[ 039 154 ]
THRM1:
Enabled
[ 039 129 ]
THRM1:
Replica block EXT
[ 039 150 ]
THRM1:
Setting error,block.
[ 039 126 ]
THRM1:
Block. by CTA error
305 221
Fig. 3-111: THRM1: Not ready
3.24.3 Tripping Characteristics
The maximum phase current IP,max.y of the selected transformer end is used to
track a first-order thermal replica according to IEC 255-8. The following
parameters will govern the tripping parameters:
The set thermal time constant (τ) of the protected object
THRM1: Tim.const.1,>Ibl PSx
The tripping threshold Δϑ
trip
set at THRM1: Rel. O/T trip PSx
The accumulated thermal load Δϑ
0
The updated measured coolant temperature Θ
c
for the protected object
The maximum permissible coolant temperature Θ
c,max
set at
THRM1: Max.perm.cool.tmpPSx
The maximum permissible object temperature Θ
max
set at
THRM1: Max.perm.obj.tmp.PSx
The object temperature is calculated from the current I
P,max.y
and can be
displayed at THRM1: Object temperat.,TH1. The coolant temperature is
either measured via the PT 100 input or via a 20 mA input, or a default
temperature value is used instead. This choice is governed by the setting at
THRM1: Select CTA PSx. The coolant temperature is displayed at
THRM1: Coolant temp. TH1. The difference between the settings for the
maximum permissible temperatures of the protected object and the coolant can
be displayed at THRM1: O/T f.Iref persist 1.
The tripping characteristics are then defined by the equation:
t = τ ln
(
I
I
ref
)
2
Δϑ
0
(
I
I
ref
)
2
Δϑ
trip
(
1
Θ
c
Θ
c,max
Θ
max
Θ
c,max
)
The setting for the operating mode selects an “absolute” or “relative” replica. If
the setting is for “Absolute replica”, the P631 will operate with a fixed trip
threshold Δ
trip
of 100 %.
P631
3 Operation
3-146 P631/EN M/R-11-C // P631-310-650
