3.3 Configuration of the Measured Value Panels (Function
Group LOC)
The P631 offers Measured Value Panels, which display the measured values
relevant at a given time.
During normal power system operation, the Operation Panel is displayed. If the
Operation Panel is activated as an event occurs, the display switches to the
appropriate Event Panel – provided that measured values have been selected for
the Event Panels. In the event of overload or ground fault events, the display will
automatically switch to the Operation Panel at the end of the event. In the event
of a fault, the Fault Panel remains active until the LED indicators or the fault
memories are reset.
