8 INFORMATION AND CONTROL FUNCTIONS
8.1 Operation
The P631 generates a large number of signals, processes binary input signals,
and acquires measured data during fault-free operation of the protected object
as well as fault-related data. A number of counters are available for statistical
purposes. This information can be read out from the integrated local control
panel or via the operating program.
All this information can be found in the “Operation” and “Events” folders in the
menu tree.
Note
Detailed information about all parameters, including complete selection tables and
IEC 60870‑5‑103 protocol properties, are separately available as a set of interlinked
PDF files for user-friendly navigation, packed in one ZIP archive named
DataModelExplorer_P631_en_P01.zip.
A list of the Logical Nodes that have been implemented for the IEC 61850 protocol
can be found in a separate document.
P631
P631/EN M/R-11-C // P631-310-650 8-1
