9.6 GOOSE Publishing
9.6.1 System/LLN0
Parameter
Network Parameters Multicast MAC Address
Virtual MAC address that the sending device provides as the destination; preset.
Application ID (hex)
Explicitly (and uniquely) assigned ID-number of the GOOSE.
VLAN Identifier (hex)
ID-number of the virtual LAN with which the GOOSE is sent; preset.
VLAN Priority
Priority with which the GOOSE is sent in the virtual LAN; preset.
Parameter
Repeat Message
Transmission
Parameters
Minimum Cycle Time
First send repetition of the GOOSE occurring after the set time period; preset.
Maximum Cycle Time
Continuous send repetition of the GOOSE occurring after the set time period;
preset.
Increment
Specification factor for the transition of time intervals for GOOSE send
repetitions from the first to the continuous repetition.
9 IEC 61850 Settings via IED Configurator
P631
P631/EN M/R-11-C // P631-310-650 9-7
