Seismic Test
Per EN 60255‑21‑3 or IEC 60255‑21‑3, test procedure A, class 1.
Frequency range
●
5 to 8 Hz, 3.5 mm / 1.5 mm, 8 to 35 Hz, 10 / 5 m/s², 3 x 1 cycle.
2.3.1.5 Mechanical Robustness 2
Applicable to the following case variants:
●
Flush mounted case, flush-mounting method 2 (with angle brackets and
frame)
●
Surface-mounted case
Vibration Test
Per EN 60255‑21-1 or IEC 60255‑21-1, test severity class 2.
Frequency range in operation
●
10 to 60 Hz, 0.075 mm, and
●
60 to 150 Hz, 1.0 g
Frequency range during transport
●
10 to 150 Hz, 2 g
Shock Response and Withstand Test, Bump Test
Per EN 60255-21-2 or IEC 60255-21-2.
Acceleration and pulse duration:
●
Shock Response tests are carried out to verify full operability (during
operation), test severity class 2:
10 g for 11 ms.
●
Shock Withstand tests are carried out to verify the endurance (during
transport), test severity class 1:
15 g for 11 ms.
●
Shock bump tests are carried out to verify permanent shock (during
transport), test severity class 1:
10 g for 16 ms.
Seismic Test
Per EN 60255‑21‑3 or IEC 60255‑21‑3, test procedure A, class 2.
Frequency range
●
5 to 8 Hz, 7.5 mm / 3.5 mm, 8 to 35 Hz, 20 / 10 m/s², 3 x 1 cycle.
2.3.2 Routine Tests
All tests per EN 60255-1.
Voltage Test
Per EN 60255-27.
●
2.2 kV AC, 1 s
Only direct voltage (2.8 kV DC) must be used for the voltage test on the power
supply inputs.
The PC interface must not be subjected to the voltage test.
