9.4 SNTP
The category “SNTP” contains the clock synchronization settings.
9.4.1 General Config
Parameter
Client Operation Poll Rate (seconds)
Polling interval for clock synchronization.
Accepted Stratum Level
Quality criterion to accept an SNTP server for clock synchronization; preset,
cannot be modified.
9.4.2 External Server 1
Settings for the primary clock synchronization server.
Note that all values except IP Address and the “Use Anycast” button are usually
disabled and may be accepted only when imported from an XML configuration
file.
Parameter Address
External Server
Parameters
IP Address
104 202
IP address of the preferred server used for clock synchronization.
Clicking the “Use Anycast” button in the IED Configurator changes the value
such that any server in the local network is appointed to provide clock
synchronization.
9.4.3 External Server 2
Settings for the primary clock synchronization server.
Note that all values except IP Address and the “Use Anycast” button are usually
disabled and may be accepted only when imported from an XML configuration
file.
Parameter Address
External Server
Parameters
IP Address
104 210
IP address of the backup server used for clock synchronization.
Clicking the “Use Anycast” button in the IED Configurator changes the value
such that any server in the local network is appointed to provide clock
synchronization.
9 IEC 61850 Settings via IED Configurator
P631
P631/EN M/R-11-C // P631-310-650 9-5
