10.2 Commissioning Tests
10.2.1 Preparation
After the P631 has been installed and connected as described in Chapter
“Installation and Connection”, the commissioning procedure can begin.
Before turning on the power supply voltage, the following items must be checked
again:
●
Is the device connected to the protective ground at the specified location?
●
Does the nominal voltage of the battery agree with the nominal auxiliary
voltage of the device?
●
Are the current and voltage transformer connections, grounding, and phase
sequences correct?
After the wiring work is completed, check the system to make sure it is properly
isolated. The conditions given in VDE 0100 must be satisfied.
Once all checks have been made, the power supply voltage may be turned on.
After voltage has been applied, the device starts up. During startup, various
startup tests are carried out (see Section 3.14, (p. 3-91)). The LED indicators for
HEALTHY (H1) and OUT OF SERVICE (H2) will light up. After approximately 15 s,
the P631 is ready for operation. By default (factory setting) or after a cold restart,
the device type “P631” and the time are displayed on the first line of the LCD
after the device has started up.
Once the change enabling command has been issued (see Section 6.11.3, (p. 6-
18)), all settings can be entered. The procedure for entering settings from the
integrated local control panel is described in Section 6.11.4, (p. 6-21).
If either the PC interface or the communication interface will be used for setting
the P631 and reading out event records, then the following settings must first be
made from the integrated local control panel.
Par/DvID menu branch:
●
DVICE: Device password 1
●
DVICE: Device password 2
