3.20 Fault Recording (Function Group FT_RC)
3.20.1 Start of Fault Recording
A fault exists and fault recording begins if at least one of the following signals is
present:
●
MAIN: General starting
●
MAIN: Gen. trip signal 1
●
MAIN: Gen. trip signal 2
●
FT_RC: Trigger
●
FT_RC: Id> triggered
●
FT_RC: IR> triggered
In addition fault recording may also be started manually using setting
parameters or externally through an appropriately configured binary signal input.
