2.5.7 Output Relays
Binary I/O Module X(4H)
with high-break contacts, applicable to
DC circuits only.
All other modules
Rated voltage: 250 V DC 250 V DC, 250 V AC.
Continuous
current:
10 A 5 A
Short-duration
current:
●
250 A for 0.03 s,
●
30 A for 3 s
30 A for 0.5 s.
Making capacity: 30 A 1000 W (VA) at L/R = 40 ms.
Breaking capacity:
●
7500 W resistive or 30 A at
250 V DC,
Maximum values: 30 A and
300 V DC.
●
2500 W inductive (L/R = 40 ms) or
10 A at 250 V DC,
Maximum values: 10 A and
300 V DC.
●
0.2 A at 220 V DC and L/
R = 40 ms,
●
4 A at 230 V AC and cos φ = 0.4.
Operating time: less than 0.2 ms less than 5 ms
Reset time: less than 8 ms less than 5 ms
2.5.8 BCD Measured Data Output
Maximum numerical value that can be displayed: 399
