Parameter Address
Default Min Max Unit Logic Diagram
Measuring-circuit
monitoring
MCM_1: Enable PSx
081 038 082 038 083 038 084 038
0: No
[spacer]
MCM_2: Enable PSx
081 039 082 039 083 039 084 039
0: No
[spacer]
This setting defines the parameter subset in which measuring-circuit monitoring
is enabled.
[spacer]
MCM_1: Ineg/Ipos> PSx
081 042 082 042 083 042 084 042
0.30 0.20 1.00 Fig. 3-124, (p. 3-157)
[spacer]
MCM_2: Ineg/Ipos> PSx
081 043 082 043 083 043 084 043
0.30 0.20 1.00
[spacer]
Setting for the operate value for the ratio I
neg
/I
pos
.
(I
neg
= negative-sequence current, I
pos
= positive-sequence current)
[spacer]
MCM_1: Operate delay PSx
081 046 082 046 083 046 084 046
5.00 0.10 100.00 s Fig. 3-124, (p. 3-157)
[spacer]
MCM_2: Operate delay PSx
081 047 082 047 083 047 084 047
5.00 0.10 100.00 s
[spacer]
Setting for the operate delay.
7.1.3.4 Control
Parameter Address
Default Min Max Unit Logic Diagram
Main function
MAIN: Cmd.end f.K200 fail.
221 111
1: Yes
[spacer]
In the case of direct motor control by motor relay K200, this parameter can be
set to Yes or No. If the K200 contacts should not have opened until the end of
the command to the motor when the set monitoring time-delay had expired
(monitoring via binary signal input –U 706, signal SIG_1: Signal S012 EXT
as the standard setting) then the direction control contacts are opened if this
parameter is set to Yes.
If this parameter is set to No then respective fault signals (MAIN: K200 fail.
cmd. end, MAIN: K200 fail. cmd.start, MAIN: DEV op.time
exceeded) are issued when the monitoring time-delay has expired and the
direction control contacts will remain closed. (Note: This behavior still bears the
danger of an undefined switch position!)
P631
7 Settings
7-122 P631/EN M/R-11-C // P631-310-650
