Parameter Address
Default Min Max Unit Logic Diagram
“Logical”
communication
interface 1
COMM1: Sel.spontan.sig.test
003 180
060 000: MAIN: Without function Fig. 3-13, (p. 3-18)
[spacer]
Signal selection for testing purposes.
[spacer]
COMM1: Test spont.sig.start
003 184
0: don't execute Fig. 3-13, (p. 3-18)
[spacer]
Triggering of transmission of a selected signal as “starting”.
[spacer]
COMM1: Test spont.sig. end
003 186
0: don't execute Fig. 3-13, (p. 3-18)
[spacer]
Triggering of transmission of a selected signal as “ending”.
[spacer]
COMM1: Sel. pos. dev.test
221 105
0: Not assigned
[spacer]
Select a device DEVxx for testing the transmission of switchgear device position
in monitoring direction.
[spacer]
COMM1: Test position dev.
221 106
0: don't execute
[spacer]
Carry out a test to check the transmission of switchgear device position in
monitoring direction for the device selected at COMM1: Sel. pos.
dev.test.
Parameter Address
Default Min Max Unit Logic Diagram
“Logical”
communication
interface 2
COMM2: Sel.spontan.sig.test
103 180
060 000: MAIN: Without function Fig. 3-15, (p. 3-20)
[spacer]
Signal selection for testing purposes.
[spacer]
COMM2: Test spont.sig.start
103 184
0: don't execute Fig. 3-15, (p. 3-20)
[spacer]
Triggering of transmission of a selected signal as "starting".
[spacer]
COMM2: Test spont.sig. end
103 186
0: don't execute Fig. 3-15, (p. 3-20)
[spacer]
Triggering of transmission of a selected signal as "ending".
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-83
