Parameter Address
Default Min Max Unit Logic Diagram
IEC Generic
Substation Status
Events
GSSE: Function group GSSE
056 060
0: Without
[spacer]
Cancelling function group GSSE or including it in the configuration.
If the function group is cancelled from the configuration, then all associated
settings and signals are hidden. Parameters included in this function group are
only effective when function group IEC is configured and enabled and when the
parameters in this function group have been activated by setting the parameter
IEC: Switch Config. Bank.
[spacer]
GSSE: General enable USER
104 049
0: No
[spacer]
Enabling and disabling function group GSSE.
[spacer]
GSSE: Min. cycle
104 052
10 1 60 ms
[spacer]
Minimum value for the GSSE repetition cycle time in ms. The repetition cycle
time for a GSSE message is calculated, according to a standard, with this
formula:
Repetition cycle time = Min. cycle + (1 + (increment/1000))
N-1
[ms]
The repetitions counter N will be restarted at count 1 after each state change of
a GSSE bit pair.
[spacer]
GSSE: Max. cycle
104 053
1 1 60 s
[spacer]
Maximum value for the GSSE repetition cycle time in s. For the formula to
calculate the repetition cycle time see GSSE: Min. cycle. Should the
calculated value for the repetition cycle time be equal to or greater than the set
max. value then the GSSE message will be sent repeatedly at the set max. value
time.
[spacer]
GSSE: Increment
104 054
900 0 999
[spacer]
Increment for the GSSE repetition cycle. For the formula to calculate the
repetition cycle time see GSSE: Min. cycle.
[spacer]
GSSE: Operating mode
104 055
0: Promiscuous
[spacer]
In the operating mode Broadcast all GSSE, independent of their MAC address
(network hardware characteristic), are always read and processed. In the
operating mode Promiscuous and after all GSSE sending devices have logged-
on, only messages with the MAC addresses of IEDs, that have logged-on
successfully, are read and processed.
[spacer]
GSSE: Output 1 bit pair
104 101
0: No selection
P631
7 Settings
7-38 P631/EN M/R-11-C // P631-310-650
