Micom P631 - Page 340

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
GSSE: Output 21 bit pair
104 161
0: No selection
[spacer]
GSSE: Output 22 bit pair
104 164
0: No selection
[spacer]
GSSE: Output 23 bit pair
104 167
0: No selection
[spacer]
GSSE: Output 24 bit pair
104 170
0: No selection
[spacer]
GSSE: Output 25 bit pair
104 173
0: No selection
[spacer]
GSSE: Output 26 bit pair
104 176
0: No selection
[spacer]
GSSE: Output 27 bit pair
104 179
0: No selection
[spacer]
GSSE: Output 28 bit pair
104 182
0: No selection
[spacer]
GSSE: Output 29 bit pair
104 185
0: No selection
[spacer]
GSSE: Output 30 bit pair
104 188
0: No selection
[spacer]
GSSE: Output 31 bit pair
104 191
0: No selection
[spacer]
GSSE: Output 32 bit pair
104 194
0: No selection
[spacer]
Setting with which GSSE bit pair the configured binary signal of the virtual GSSE
outputs is to be transmitted. A GSSE is always transmitted consisting of a fixed
number of 96 bit pairs, of which a maximum of 32 are used by this device (IED)
during a send operation.
[spacer]
GSSE: Output 1 fct.assig.
104 102
060 000: MAIN: Without function
[spacer]
GSSE: Output 2 fct.assig.
104 105
060 000: MAIN: Without function
[spacer]
GSSE: Output 3 fct.assig.
104 108
060 000: MAIN: Without function
[spacer]
GSSE: Output 4 fct.assig.
104 111
060 000: MAIN: Without function
[spacer]
GSSE: Output 5 fct.assig.
104 114
060 000: MAIN: Without function
P631
7 Settings
7-40 P631/EN M/R-11-C // P631-310-650
