Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
GSSE: Output 25 fct.assig.
104 174
060 000: MAIN: Without function
[spacer]
GSSE: Output 26 fct.assig.
104 177
060 000: MAIN: Without function
[spacer]
GSSE: Output 27 fct.assig.
104 180
060 000: MAIN: Without function
[spacer]
GSSE: Output 28 fct.assig.
104 183
060 000: MAIN: Without function
[spacer]
GSSE: Output 29 fct.assig.
104 186
060 000: MAIN: Without function
[spacer]
GSSE: Output 30 fct.assig.
104 189
060 000: MAIN: Without function
[spacer]
GSSE: Output 31 fct.assig.
104 192
060 000: MAIN: Without function
[spacer]
GSSE: Output 32 fct.assig.
104 195
060 000: MAIN: Without function
[spacer]
Function assignment of a binary logical state signal to the virtual GSSE outputs.
The signal configured here is sent through the GSSE bit pair as configured
above.
[spacer]
GSSE: Input 1 bit pair
105 001
0: No selection
[spacer]
GSSE: Input 2 bit pair
105 006
0: No selection
[spacer]
GSSE: Input 3 bit pair
105 011
0: No selection
[spacer]
GSSE: Input 4 bit pair
105 016
0: No selection
[spacer]
GSSE: Input 5 bit pair
105 021
0: No selection
[spacer]
GSSE: Input 6 bit pair
105 026
0: No selection
[spacer]
GSSE: Input 7 bit pair
105 031
0: No selection
[spacer]
GSSE: Input 8 bit pair
105 036
0: No selection
[spacer]
GSSE: Input 9 bit pair
105 041
0: No selection
P631
7 Settings
7-42 P631/EN M/R-11-C // P631-310-650
