Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
GSSE: Input 29 bit pair
105 141
0: No selection
[spacer]
GSSE: Input 30 bit pair
105 146
0: No selection
[spacer]
GSSE: Input 31 bit pair
105 151
0: No selection
[spacer]
GSSE: Input 32 bit pair
105 156
0: No selection
[spacer]
Setting which GSSE bit pair is assigned to which virtual GSSE input. A GSSE is
always received consisting of a fixed number of 96 bit pairs, of which a
maximum of 32 are processed by this device (IED).
[spacer]
GSSE: Input 1 IED name
105 002
1: Remote IED
[spacer]
GSSE: Input 2 IED name
105 007
1: Remote IED
[spacer]
GSSE: Input 3 IED name
105 012
1: Remote IED
[spacer]
GSSE: Input 4 IED name
105 017
1: Remote IED
[spacer]
GSSE: Input 5 IED name
105 022
1: Remote IED
[spacer]
GSSE: Input 6 IED name
105 027
1: Remote IED
[spacer]
GSSE: Input 7 IED name
105 032
1: Remote IED
[spacer]
GSSE: Input 8 IED name
105 037
1: Remote IED
[spacer]
GSSE: Input 9 IED name
105 042
1: Remote IED
[spacer]
GSSE: Input 10 IED name
105 047
1: Remote IED
[spacer]
GSSE: Input 11 IED name
105 052
1: Remote IED
[spacer]
GSSE: Input 12 IED name
105 057
1: Remote IED
[spacer]
GSSE: Input 13 IED name
105 062
1: Remote IED
P631
7 Settings
7-44 P631/EN M/R-11-C // P631-310-650
