Micom P631 - Page 347

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
GSSE: Input 18 default
105 088
0: 0
[spacer]
GSSE: Input 19 default
105 093
0: 0
[spacer]
GSSE: Input 20 default
105 098
0: 0
[spacer]
GSSE: Input 21 default
105 103
0: 0
[spacer]
GSSE: Input 22 default
105 108
0: 0
[spacer]
GSSE: Input 23 default
105 113
0: 0
[spacer]
GSSE: Input 24 default
105 118
0: 0
[spacer]
GSSE: Input 25 default
105 123
0: 0
[spacer]
GSSE: Input 26 default
105 128
0: 0
[spacer]
GSSE: Input 27 default
105 133
0: 0
[spacer]
GSSE: Input 28 default
105 138
0: 0
[spacer]
GSSE: Input 29 default
105 143
0: 0
[spacer]
GSSE: Input 30 default
105 148
0: 0
[spacer]
GSSE: Input 31 default
105 153
0: 0
[spacer]
GSSE: Input 32 default
105 158
0: 0
[spacer]
Default for the virtual binary GSSE input. The state of a virtual two-pole GSSE
input will revert to default as soon as the continuously monitored
communication link to a GSSE sending device (IED situated on the opposite side)
is in fault or has disappeared altogether.
[spacer]
GSSE: Input 1 fct.assig.
105 004
061 000: MAIN: Without function
[spacer]
GSSE: Input 2 fct.assig.
105 009
061 000: MAIN: Without function
