Micom P631 - Page 354

Parameter Address
Default Min Max Unit Logic Diagram
Measured data input
MEASI: Function group MEASI
056 030
0: Without
[spacer]
Cancelling function group MEASI or including it in the configuration.
If the function group is cancelled from the configuration, then all associated
settings and signals are hidden.
[spacer]
MEASI: General enable USER
011 100
0: No Fig. 3-23, (p. 3-38)
Fig. 3-31, (p. 3-47)
[spacer]
Disabling or enabling analog measured data input.
[spacer]
MEASI: Enable IDC p.u.
037 190
0.000 0.000 0.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
Setting for the minimum current that must flow in order for the P631 to display a
measured value > 0 (zero suppression).
[spacer]
MEASI: IDC< open circuit
037 191
3.0 0.0 10.0 mA Fig. 3-26, (p. 3-41)
[spacer]
If the input current falls below the set threshold, the P631 will issue an “open
circuit” signal.
[spacer]
MEASI: IDC 1
037 150
0.000 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC 2
037 152
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC 3
037 154
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC 4
037 156
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC 5
037 158
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC 6
037 160
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC 7
037 162
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC 8
037 164
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC 9
037 166
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
[spacer]
MEASI: IDC 10
037 168
Blocked 0.000 1.200 IDC,nom Fig. 3-26, (p. 3-41)
