Parameter Address
Default Min Max Unit Logic Diagram
Differential protec‐
tion
DIFF: Function group DIFF
056 027
0: Without
[spacer]
Cancelling function group DIFF or including it in the configuration. If the function
group is cancelled from the configuration, then all associated settings and
signals are hidden.
Parameter Address
Default Min Max Unit Logic Diagram
Definite-time over‐
current protection
DTOC1: Function group DTOC1
056 031
0: Without
[spacer]
DTOC2: Function group DTOC2
056 032
0: Without
[spacer]
Canceling function group DTOC1 / DTOC2 or including it in the configuration.
If a function group is cancelled from the configuration, then all associated
settings and signals are hidden, with the exception of this setting.
Parameter Address
Default Min Max Unit Logic Diagram
Inverse-time overcur‐
rent protection
IDMT1: Function group IDMT1
056 051
0: Without
[spacer]
IDMT2: Function group IDMT2
056 061
0: Without
[spacer]
Cancelling function groups IDMT1 and IDMT2 or including them in the
configuration. If a function group is cancelled, then all associated settings and
signals are hidden, with the exception of this setting.
Parameter Address
Default Min Max Unit Logic Diagram
Thermal overload
protection
THRM1: Function group THRM1
056 054
0: Without
[spacer]
Cancelling function group THR_1 or including it in the configuration. If the
function group is cancelled, then all associated settings and signals are hidden,
with the exception of this setting.
P631
7 Settings
7-68 P631/EN M/R-11-C // P631-310-650
