Parameter Address
Default Min Max Unit Logic Diagram
Definite-time over‐
current protection
DTOC1: General enable USER
031 135
0: No Fig. 3-91, (p. 3-124)
[spacer]
DTOC2: General enable USER
031 136
0: No
[spacer]
Enabling/disabling the definite-time overcurrent protection function.
[spacer]
DTOC1: Select. meas. input
019 103
0: End a Fig. 3-90, (p. 3-123)
[spacer]
DTOC2: Select. meas. input
019 104
1: End b
[spacer]
Selection of the measuring input that provides the measured values monitored
by the definite-time overcurrent protection function.
Parameter Address
Default Min Max Unit Logic Diagram
Inverse-time overcur‐
rent protection
IDMT1: General enable USER
031 141
0: No Fig. 3-98, (p. 3-132)
[spacer]
IDMT2: General enable USER
031 142
0: No
[spacer]
Disabling and enabling the inverse-time overcurrent protection function.
[spacer]
IDMT1: Select. meas. input
019 106
0: End a Fig. 3-97, (p. 3-131)
[spacer]
IDMT2: Select. meas. input
019 116
1: End b
[spacer]
Selection of the measuring input that provides the measured variables
monitored by the inverse-time overcurrent protection function.
P631
7 Settings
7-80 P631/EN M/R-11-C // P631-310-650
