Micom P631 - Page 392

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
LOGIC: Fct.assignm. outp.28
031 008
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm. outp.29
031 012
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm. outp.30
031 016
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm. outp.31
031 020
060 000: MAIN: Without function
[spacer]
LOGIC: Fct.assignm. outp.32
031 024
060 000: MAIN: Without function
[spacer]
These settings assign functions to the outputs.
[spacer]
LOGIC: Op. mode t output 1
030 001
0: Without timer stage Fig. 3-141, (p. 3-174)
[spacer]
LOGIC: Op. mode t output 2
030 005
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 3
030 009
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 4
030 013
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 5
030 017
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 6
030 021
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 7
030 025
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 8
030 029
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 9
030 033
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 10
030 037
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 11
030 041
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 12
030 045
0: Without timer stage
[spacer]
LOGIC: Op. mode t output 13
030 049
0: Without timer stage
P631
7 Settings
7-92 P631/EN M/R-11-C // P631-310-650
