Micom P631 - Page 435

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
GOOSE: Output 18 state
106 044
0: 0
[spacer]
GOOSE: Output 19 state
106 046
0: 0
[spacer]
GOOSE: Output 20 state
106 048
0: 0
[spacer]
GOOSE: Output 21 state
106 050
0: 0
[spacer]
GOOSE: Output 22 state
106 052
0: 0
[spacer]
GOOSE: Output 23 state
106 054
0: 0
[spacer]
GOOSE: Output 24 state
106 056
0: 0
[spacer]
GOOSE: Output 25 state
106 058
0: 0
[spacer]
GOOSE: Output 26 state
106 060
0: 0
[spacer]
GOOSE: Output 27 state
106 062
0: 0
[spacer]
GOOSE: Output 28 state
106 064
0: 0
[spacer]
GOOSE: Output 29 state
106 066
0: 0
[spacer]
GOOSE: Output 30 state
106 068
0: 0
[spacer]
GOOSE: Output 31 state
106 070
0: 0
[spacer]
GOOSE: Output 32 state
106 072
0: 0
[spacer]
Display of the virtual binary GOOSE output state.
[spacer]
GOOSE: Input 1 state
106 200
0: 0
[spacer]
GOOSE: Input 2 state
106 201
0: 0
[spacer]
GOOSE: Input 3 state
106 202
0: 0
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-13
