Micom P631 - Page 457

Parameter Address
Default Min Max Unit Logic Diagram
[spacer]
GOOSE: IED20 link faulty
107 203
0: No
[spacer]
GOOSE: IED21 link faulty
107 204
0: No
[spacer]
GOOSE: IED22 link faulty
107 205
0: No
[spacer]
GOOSE: IED23 link faulty
107 206
0: No
[spacer]
GOOSE: IED24 link faulty
107 207
0: No
[spacer]
GOOSE: IED25 link faulty
107 208
0: No
[spacer]
GOOSE: IED26 link faulty
107 209
0: No
[spacer]
GOOSE: IED27 link faulty
107 210
0: No
[spacer]
GOOSE: IED28 link faulty
107 211
0: No
[spacer]
GOOSE: IED29 link faulty
107 212
0: No
[spacer]
GOOSE: IED30 link faulty
107 213
0: No
[spacer]
GOOSE: IED31 link faulty
107 214
0: No
[spacer]
GOOSE: IED32 link faulty
107 215
0: No
[spacer]
Display whether GOOSE receipt of the configured signal is faulty or not
available. To each GOOSE the GOOSE sending device will attach a validity
stamp, up to which a repetition of GOOSE will be carried out independent of a
change of state. Thus the protection and control unit monitors the time period at
which the next state signal must be received.
[spacer]
GOOSE: ExtDev01 link faulty
107 216
0: No
[spacer]
GOOSE: ExtDev02 link faulty
107 217
0: No
[spacer]
GOOSE: ExtDev03 link faulty
107 218
0: No
[spacer]
GOOSE: ExtDev04 link faulty
107 219
0: No
8 Information and Control Functions
P631
P631/EN M/R-11-C // P631-310-650 8-35
