Micom P631 - Page 486

Parameter Address
Default Min Max Unit Logic Diagram
Inverse-time overcur‐
rent protection
IDMT2: Block. tIref,P> EXT
038 134
0: No
[spacer]
IDMT2: Block.tIref,neg> EXT
038 188
0: No
[spacer]
IDMT2: Block. tIref,N> EXT
038 144
0: No
[spacer]
IDMT2: Enabled
038 145
0: No
[spacer]
IDMT2: General starting
038 135
0: No
[spacer]
IDMT2: tGS elapsed
038 136
0: No
[spacer]
IDMT2: Starting Iref,P>
038 130
0: No
[spacer]
IDMT2: Starting Iref,A>
038 137
0: No
[spacer]
IDMT2: Starting Iref,B>
038 138
0: No
[spacer]
IDMT2: Starting Iref,C>
038 139
0: No
[spacer]
IDMT2: tIref,P> elapsed
038 131
0: No
[spacer]
IDMT2: Hold time P running
038 132
0: No
[spacer]
IDMT2: Memory P clear
038 133
1: Yes
[spacer]
IDMT2: Starting Iref,neg>
038 183
0: No
[spacer]
IDMT2: tIref,neg> elapsed
038 184
0: No
[spacer]
IDMT2: Trip sig. tIref,neg>
038 187
0: No
[spacer]
IDMT2: Hold time neg runn.
038 185
0: No
[spacer]
IDMT2: Memory 'neg' clear
038 186
1: Yes
